Specifications of condenser and evaporator coils |
||||
|
NO |
Tube Diameter(mm) |
Distance of hole/row(mm) |
Fin Style |
Fin Space(mm) |
|
1 |
Φ7 |
21*12.7 |
Louvered fin,Plain fin,Sine wave fin |
1.4~2.0 |
|
2 |
Φ7 |
21*18.9 |
Sine wave fin,Corrugated fin |
1.3~1.9 |
|
3 |
Φ7 |
25*21.65 |
Louvered fin |
1.5~3.8 |
|
4 |
Φ9.52 |
25.4*22 |
Louvered fin,Sine wave fin |
1.6~6.35 |
|
5 |
Φ9.52 |
25.4*22 |
Louverd fin,Plain fin,Sine wave fin |
1.6~3.2 |
|
6 |
Φ9.52 |
25*19 |
Louverd fin,Plain fin,Sine wave fin |
1.4~3.2 |
|
7 |
Φ9.52 |
25*21.65 |
Louvered fin,V ripple fin |
2.0~3.8 |
|
8 |
Φ9.52 |
25*25 |
Plain fin |
1.6~3.2 |
|
9 |
Φ9.52 |
25*21.65 |
Plain fin |
2.0~6.0 |
|
10 |
Φ9.52 |
25.4*22 |
Louvered fin,Plain fin,Sine wave fin |
1.6~6.35 |
|
11 |
Φ9.52 |
31.75*27.5 |
Louvered fin,Plain fin,Sine wave fin |
1.6~6.35 |
|
12 |
Φ12.7 |
31.75*27.5 |
Plain fin,Sine wave fin,V ripple fin |
1.8~6.0 |
|
13 |
Φ12.7 |
31.75*27.5 |
Louvered fin,Plain fin,Sine wave fin,V ripple fin |
1.7~2.2 |
|
14 |
Φ12.7 |
31.75*27.5 |
corrugated fin |
1.6~2.9 |
|
15 |
Φ15.88 |
38.1*33 |
Plain fin,Sine wave fin,V ripple fin |
2~4 |
|
1.5~4.1 |
1.5~4.2 |
1.5~4.3 |
1.5~4.4 |
1.5~4.5 |
We can serve for more types of evaporator according to every customers' drawing and requirement
|
|
Series 1 |
Series 2 |
Series 3 |
Series 4 |
|
Tube Diameter |
Φ 9.52 |
Φ9.52 |
Φ7 |
Φ 7.94 |
|
Hole Space(mm) |
25 |
25.4 |
20.5 |
22 |
|
Row Space(mm) |
21.65 |
22 |
12.7 |
19.05 |
|
Tube Material |
Copper, Aluminum |
Copper, Aluminum |
Copper, Aluminum |
Copper, Aluminum |
|
Type of Tube |
Smooth Tube |
Smooth Tube |
Smooth Tube |
Smooth Tube |
|
Fin Surface |
Louver Fin |
Flat Fin |
Flat Fin |
Louver Fin |
|
Fin Type |
Hydrophilic Foil |
Hydrophilic Foil |
Hydrophilic Foil |
Hydrophilic Foil |
|
Fin Thickness(mm) |
0.095~0.2 |
0.095~0.2 |
0.095~0.2 |
0.095~0.2 |
|
Fin Space(mm) |
1.4~2.3 mm |
1.4~2.3 mm |
1.1~1.8mm |
1.4~2.0 mm |
York makes these replacement coils, and now they are part of Johnson Controls, which also handles stuff like Luxaire and Coleman. A lot of their problems are pretty standard in the HVAC world, but there are some things that stand out just for York.
One big one is those SmartCoil evaporator coils from the late 1990s up to the early 2010s. They were supposed to be super efficient, but honestly, they had this flaw with the micro-channel aluminum tubing that had grooves inside. It makes them really susceptible to formicary corrosion and these tiny pinhole leaks. I think thats why so many fail way too early, like after 5 to 12 years. Its a York thing that technicians talk about a lot.
Then there are the drain pans that rust out fast. Some models use galvanized steel, and it just corrodes through before it should, causing water leaks and damage everywhere. You end up having to swap the whole coil and drain pan setup.
Corrosion hits in places like coastal areas or where its humid or acidic. That eats at the aluminum fins and copper tubes no matter what. And beyond the SmartCoil mess, there have been batches of regular tube-and-fin coils with way more leaks than normal. Its not rare for folks who work on these systems.
Choose us, make better York Replacement Coils.
Our Advantages
- We have customized products for many customers, following are some projects we did before.
- We can provide designing data and production drawings.
- We promise we use the design software sold by a well-known European HAVC software company. Through 8 years of cooperation with them, we have designed, processed and exported dry coolers to various countries all around the world.
- All of customers feedback is that the actual cooling performance is almost the same as the theoretical design value.
Packaging & Shipping
The normal package is wooden box. If export to european countries, the wooden box will be fumigated. If container is too tighter, we will use pe film for packing or pack it according to customers special request.
lead Time
20 - 40 days
Payment Terms
50% T/T payment in advance, 50% T/T payment before delivery
Packing Condition
Standard export packing or customized packaging
